Fully customizable Google Forms
2019-08-21 21:02
TOC
本篇中文版：完全客製 Google 表單，美化表單樣式
Google Forms is very convenient, but it can be used better
We usually use the google form: enter the google drive, add a google form, and then use its WYSIWYG UI to create a form and use.
Of course, this is the quickest way, but it is less design.
Even if google forms uses the material design in the UI, you can upload the key vision of the by yourself, which is not comparable to the designer’s design.
I often have problems with data storage recently. Free database in addition to firebase, if you just want to save simple fields, google excel is a good choice.
Before writing an article on how to use google excel as a database, this first writes how to use google forms as a form on the web page.
This article will use the “Contact Us” form as an example.
Tools used in this article:
- form contents：Google Forms
- form style：Skeleton
Design the required fields and create them with Google Forms
In web page, we often use these material in form:
- input
- radio
- select
- textarea
So, the demo form use those fields:
- name (input)
- gender (radio)
- category (select)
- question (textarea)
Google forms basically don’t need teaching, but pay attention to:
Regardless of whether the field is input or radio, select, or textarea, you should select the format of “short answer” when creating the form.
Because in the end, values are passed to google excel, so the value of each field is actually obtain by the form of the web page, instead of being obtained through google forms.
What we get from google forms is the url of the action and the name of each input.
This is the demo form：
After the form is finished, remember to go to the responses and click create spreadsheet to create a google excel to see if the data is actually coming in.
Take the necessary information from google forms
The form on the web page, if you want to be able to pass data to the back-end, you need 2 things:
- POST url
- field name
Google forms will have these two things after the form is created. You can find them on the form with the DevTools.
find POST url
You right-click an element on the form page and select Inspect to jump into the Elements panel. If you use Windows system, you can press F12 directly.
elements panel
On the left is the page of the original form, and on the right is the code.
Randomly click on the code, you will see the number of selected lines become blue background:
blue background block is the code of your select
Then, if you are using a Windows system, press ctrl + F, if it is Mac, cmd + F, and you will see the search input:
open search input
Type <form in the search input and in the search results you will see some code with a yellow background.
art of search “<form”
From the code starting with <form , you can see the action tag, which has a url value. It is the POST URL and we need to copy it.
The POST url like this:
|
|
find fields name
First, click the button labeled “1” in the image below, then move the mouse to the name of the form until the position at the beginning of “input” is displayed, left-click.
find input code
After left-click, you will see the part of the code on the element panel, and there is a code width light blue background:
The selected input is highlighted
The input code is：
|
|
The name is our need tag:
|
|
The other three items are handled in the same way, all we need name are as follow：
- name：entry.2065974955
- gender：entry.1310259066
- category：entry.896842914
- question：entry.1857722787
Now we have POST url, fields name, and we can totally custom our form.
Build a web page form
This post use Skeleton to build a simple form, and the demo is as follow:
custom form demo
Although in the stage of making google forms, each question is a short answer type, but in the custom form, you can distinguish between input, radio, select, and textarea. As long as you can catch the value and post it, you can be sure that the data is received.
Custom form + Google Forms value
We have POST url、google form fields name、custom form, the next step is set google form fields name to our custom form’s name.
The google form fields name are correspond to the fields in google excel. There are two ways to set name fields:
The first way: we use the normal form method, we set the action URL and each input name, when we click the submit button, the browser will handle the submit function.
This is an example of the first way, remember to replace the url and each input name:
The second way is use AJAX, we POST google forms url dirctly, and the data’s key is input name.
This article is mainly about writing the second way.
POST to Google Forms
These information are get from google form:
- url：https://docs.google.com/forms/d/e/1FAIpQLScxpBiexGfPha5_vq1fos2r_9dl1QfkCJBvHWHRIbgwudOHaQ/formResponse
- Name name：entry.2065974955
- Gender name：entry.1310259066
- Category name：entry.896842914
- Question name：entry.1857722787
We can use them to code html and js.
HTML
JS
The part of js, we get each input value and AJAX to google form.
Usually for the form, it will verify whether the columns are empty or verify that the format is correct. But this article is mainly about how to customize the form, so I gave up the verification part. If input value is empty, I will send “no set”.
The data’s key is the name which we get from google form’s name.
The POST url is the action value which we get from google form’s action.
Finally, we can test whether the data is successfully entered into the google excel.
We fill the form and click confirm button:
fill the form
Then we open response google excel and we can see that the data came in successfully !
google excel save data successfully
The source code used in this article is here, welcome to download and use:
https://github.com/letswritetw/letswrite-customize-google-form-en
And the test web page is here: Customize google form demo
Here you can see if the data has been sent：response google excel
